| Operating Weight: | 58,354 lbs. |
|---|---|
| Rated Horsepower: | 344.6 |
| Bucket Capacity (yards): | 6.3 |
| Maximum Torque (ft-lb): | 1,180 |
Get added horsepower and a 7% larger bucket capacity than the previous model to handle more material in challenging construction and mining applications. Axle upgrades support larger bucket capacities, and a strengthened box frame provides better balance and improved lifting capacity. With the high-lift option, you’ll gain additional height for loading into high-sided trucks. An optional Load Isolation System improves stability when moving – for even higher productivity.
Other features include power-shift 4-speed transmission, multiple power modes, Z-bar lift arm, return to dig and limited slip differentials. The improved cooling system features wider radiator fin spacing and a reversible fan to clear debris and reduce clogging.
Equipped to handle the largest loads, the Develon® DL580-7 wheel loader allows operators to efficiently fill a 24-ton capacity, over-the-road truck in just two passes. The larger load capacity reduces cycle times and makes this a perfect machine for heavy-duty jobs.
The DL580-7 also has an enhanced front work group that features a reinforced Z-bar, larger-profile arm and lift cylinder geometry that improves lifting capacity. This model is built for mining and aggregate work as well as heavy-duty construction jobsites.
Options include a quick coupler, additional larger counterweight and Load Isolation System.
The exclusive Transparent Bucket option provides a supplemental visual perspective by allowing operators to “see-through” the bucket from an in-cab display.
The Develon Smart Load weighing system measures the weight of material in the bucket.
The heavy-duty Develon® DL550-7 is ideal for work in quarries, mines, demolition and industrial operations.
Performance features include a Z-bar lift arm, return to dig, limited slip rear differential, hydraulic locking front differential, and a stronger box frame for improved lifting capacity.
Options include a quick coupler, additional larger counterweight and Load Isolation System to improve stability when moving. The high-lift option provides additional height for loading into high-sided trucks.
The Develon Smart Load weighing system is ideal for job applications that require accurate information about material weight in the bucket.
The 48.8 hp Develon® DX50Z-7 mini excavator, part of the 5-metric-ton size class, offers a zero tail swing design ideal for doing challenging road building or construction projects in confined areas.
Featuring an all-Develon design, the DX50Z-7 includes an increased, integrated counterweight for improved balance when digging and lifting, a backfill blade, and a rubber track undercarriage for superior flotation and traction. A steel track undercarriage option is available for working around sharp objects.
Additional features include integrated slew brakes, torque-limiting piston pumps and a width-protected swing frame.
The highly maneuverable, extremely versatile 24.7 hp DX35Z-7 mini excavator is engineered to take on challenging digging and lifting tasks in tight spaces.
The zero tail swing design makes navigating in urban areas and around confined worksites easier than ever. The increased counterweight helps decrease machine overhang and enhances digging and lifting performance.
Keep the standard arm for maximum breakout force and lifting ability, or choose the long-arm option to avoid machine repositioning or to make loading trucks faster and easier.
Other features include integrated slew brakes, rubber track undercarriage and backfill blade.
