| Type: | Mulching Head |
|---|---|
| Attaches To: | Skid Steer |
| Operating Weight: | 5,605 lbs. – 6,680 lbs. |
| Cutting Wisth: | 80 in. |
The high-performance Battle Ax rotor with exclusive depth gauge design is available for prime movers up to 400 horsepower. It features exclusive extreme triple carbide teeth for maximum performance.
The Battle Ax features a unique rotor with built-in depth gauges to offer high performance with both sharpened knives and carbide cutting teeth. Models are available with both low – and high – flow skid steers.
The BL4/EX/VT for 18-25 ton excavators mulches logs up to 12 in in diameter and comes in two working widths: 53 in and 63 in. The BL4/EX/VT is ideal for handling and removing vegetation in wooded areas, especially for jobs that require a large shredding capacity and speed. The rotor features Bite Limiter technology. Steel profiles limit the reach (bite) of the teeth, reducing the amount of power needed and guaranteeing constant working speed and excellent performance. The heat-treated forged-steel BL blades are made to last and can be sharpened to keep operating costs lower.
The Poly Chain belt drive transmission ensures optimum power transfer and reliability.
BL2/EX/VT for 8-14 ton midsize excavators mulches trees with a max. diameter of 6 in and is available in two working widths: 39 in and 49 in.
The rotor features Bite Limiter technology.
Steel profiles limit the teeth depth of action, which reduces power demand and guarantees speed and exceptional performance every time.
Two types of fixed teeth can be used with the rotor: Mini BL blades and Mini C/3 teeth. BL2/EX/VT has a VT (Variable Torque) motor for noticeably better performance, increased torque when needed, and minimal risk of rotor stalling.
Robust and compact, the UML/SSL/VT is renowned for its ergonomic design that guarantees excellent visibility for the operator during various situations.
Thanks to the diverter valve kit option, it can be utilized with any brand of skid steer on the market.
The BL version with automatic variable displacement hydraulic motor increases productivity by up to 50% and simultaneously reduces fuel consumption.
